Home » Products » Demineralisation Plant » Demineralisation Plant

Demineralisation Plant

Demineralisation Plant
Demineralisation Plant
Product Code : 01
Product Description

Demineralisation Plant

We are involved in providing our clients an assortment of precision engineered demineralisation plant, which has huge demand in the market. This range is designed and fabricated in accordance to the technology widely applicable in most of all of industrial sectors. We offer these demineralisation plants in various specifications to meet the demand.

AQUAION Industrial two bed demineraliser (Deionisers) Type CAPTION and ANION are available in a wide range range with maximum flow rate from 1500 to 20000 LHP.

Application

  • Pharma Industry and storage batteries
  • Process water for manufacturing plants
  • Boiler feed water and electronic industries
  • Beverage and food processing industry
  • Hospital,hotel,Institute and more

Demineralization or Deionisation is the process of removing mineral salts from water by using the ion exchange process.  With most natural water sources it is possible to use Demineralisation and produce water of a higher quality than conventional distillation.

Fluid Systems Manufacture a Wide range of custom-built softening, Dematerializing plants for industrial process water applications, with inherent design to conserve water, and save costs. They are available in different sizes and materials, manually operated or fully Automatic, & ready to install & are available as standard models or custom built versions for specific needs.

Operating Principle

A Typical two-bed DM Plant consists of two FRP/MS Rubber lined Pressure vessels connected in series along with its internal fittings. The first unit consists of high capacity strongly acidic cation exchange resin, which converts positive ions of salt and replaces them with hydrogen ions to form respective acids, which are absorbed in next vessel by strongly basic anion exchange resin. The water obtained by this process shows conductivity less than 20 µ S / cm at 25o C and total dissolved solids less than 10 ppm.

Further high purity water can be achieved by Mixed Bed Deionisers, which are designed to produce high purity treated water. They can be used as polishing units after two bed DM Plant to obtain high purity water. Mixed Bed Deionisers are single column units, filled with strongly acidic cation and strongly basic anion exchange resins mixed together.

There are four distinct stages in the operation of Deionisers

  • Service
  • Backwashing
  • Regeneration
  • Rinse/remix

Service

In the Service cycle the water enters the vessel and passes through the Resin bed of the respective exchanger

Backwashing

After the resins are exhausted, the bed is backwashed. Backwashing is carried out by a uniform upward flow of water through the resin bed. The backwash step expands the resin bed releasing any entrapped particulate matter & removes the channeling in the resin column if occurred during the service cycle.

Regeneration

When the ion exchange resins loose all the exchangeable ions, they require regeneration to restore them back to hydrogen or hydroxyl form depending upon whether they are cation or anion resins. To achieve this 4 - 5% concentrated solution of Hydrochloric acid is used for cation resin and a 4% - 5% concentrated solution of caustic soda for anion resin. Sulphuric acid can also be used for Cation Regeneration but the concentration of acid during injection must be kept at minimum, such as to prevent calcium sulphate precipitation on the resin.

Rinse

The final stage of regeneration is to rinse the resins of excess regenerant

Advantages

  • Easy to install & operate
  • Complete Assembly with backwash &regeneration equipment
  • Produces DM water of high purity
